Achema 2018

Vacuum technique

In order for vacuum systems to provide reliably stable suction performances, the pipe connections must guarantee long-term tightness even at high vacuum. Depending on the medium, LINNEMANN offers the required stainless steel, aluminium or glass components in accordance with standards DIN 28403 ISO 2861 for the KF small flange connections and DIN 28404 ISO 1609 for ISO-K clamping flange connections. Required flexible connections can be supplemented from the hose program. LINNEMANN offers metal hoses as well as hoses with support spirals, which are assembled appropriately and can therefore be integrated safely.

Where disc or ball valves are required for control or for extraction, for example, various systems are available. The mechanically operating vacuum gauges can be used as robust, corrosion-resistant vacuum gauges.

(Klick to enlarge)

On ACHEMA 2018 the exhibits were combined within miscellaneous appication areas. The following links direct to the respective themes.
